Model: F-1300
Type: Triplex liner single-action
Input power: 1300 HP
Maximum stroke: 12inches ( 304.8mm)
Maximum working pressure: 5, 000 psi (35 MPa)
Gear type: Integral herringbone
Valve pots: API 7#
Intake: 12 inches (305 mm)
Discharge: 4 inches (102 mm)
Pulsation dampener Model: KB -75/Capacity: 75.7 liter (20 Gallon)
Relief valve: Model: A JA-3/Discharge size: 3 in NPT
Pressure gauge: Yk-150 0-40MPA

TECHNICAL PARAMETERS OF DIESEL ENGINE
Model: CAT 3512 (Land mechanical)
Rated power: 1250 HP
Rated speed: 1200 rpm
Revolution direction: Anticlockwise (face output shaft end)
about scope of supply seeing the attached

POWER GRIP CLUTCHES
-Type: 321 (WPT power transmission)
-Max power: 2100HP
-Max speed: 1950 r/min

Adjustable device for tightening belts

Charging pump
-Rate power: 75HP
-Displacement: 63401 Gal/H
-Max. Lift: 105 in

TESTING & COMMISSIONING
Install and secure major machinery and miscellaneous equipment
Furnish lube products for testing
Run diesel engine to test transmission devices.
