LW1-6/550 wire drawing machines, drived by gears, are capable of drawing rod wires of high-, medium-, low-carbon steel, copper, aluminium, ect. And appliable to manufacturing industries such as wood screw, nail, conducting wirerope for electrician use, spring, etc. With electrical control, this kind of machine is safe in operation, low in noise, and high in effciency.

Main technical parameter:
Specifications: Model: LW1-6/550
Diameter of the spool(mm): 550
Six vinked pots
Drawing range: 6.5-2.2mm
Speed of the spool: 27-168rpm
Power of a single machine: 15-22kw
Power motor: Six
Output: 10 T/day
Rotation Pattern: Gear Rotation
Weight: 1400kg
Overall dimensions(LxWxH): 6050x1685x2100mm
