Features:
1) With vacuum table and Auto tool changer
2) Square linear rail which has longer life and higher precision than round linear rail
3) Unique design of double-gear transmission, more simple operation

Applicable Industries & Materials:
Woodworking, building model, wood-model, propeller, foam mold of car, violin, and other musical instruments 3D surface. Shape cutting, sculpture of surface patterns of musical instruments, calligraphy plaque, carving of frames.

Technical Parameters:
Machine Model ATC JK-1325 Woodworking CNC Router
XYZ Guide Rail Square Rail
X, Y Transmission Rack Gears
Spindle Motor 8.0KW ( HSD )
Software TYPE 3/ARTCUT(English)
Operation System SYNTEC
Driver Stepper Motor
Spindle Speed 0-18000 RPM
Max Working Speed 20000mm/min
Working Voltage AC380V/50/60Hz,
Blade Diameter 3.175mm, 4mm, 6mm(or8mm, 12mm, 12.7mm)
Working Size 1300× 2500mm
X, Y, Z Repositioning Positioning Accuracy 0.05mm
X, Y Resolution 0.02mm
N. W 2000KG
G. W. 2300KG
Delivery Date 25 working days
Guarantee and After-sale service:
1 year guarantee
24 hour's technical support by e-mail or calling
Use the English manual friendly and can refer to the Video CD
