Products name: Duplex toilet or translucent soap vacuum plodder, soap equipment, soap line, soap machinery;
His mixer will be in conformity with CE, and its control to CS standard.
Rated capacity: 100 to 125 kg/batch (soap noodles)
Two Z-shaped sigma agitators inside the mixing trough the gyration diameter of the agitator is 350 mm, inclination angle 60o.
Motor: 5.5+5.5 kW
Speed: Agitator A 22 r/min
Agitator B 36 r/min
Pressure of compressed air: 0.4 MPa
Consumption of compressed air: 0.5 m3/min
All metallic parts in contact with soap are in stainless steel 304.
The property class of all threaded fasteners will be over 8.8, and with locking devices.
The threaded fasteners made from stainless steel the strength of material will not lower than that of A270.
The speed reducers for agitators are supplied by China
