Structure Angular Contact
Type: OEM
Bore Size: 100-1800mm(P0, P6)
35-360mm(P5, P4, P2)
Outside Diameter 50-2000mm
Precision Rating P0 P6 P5 P4 P2
Number of Row Single Row
Brand Name WZFB
Place of Origin Liaoning, China (Mainland)
Carbon Steel GCR15 Steel
No minimum quantity,
Short lead time
Competitive price.

The raceways of both the inner and outer rings of these non-separable bearings are made with set contact angles. The balls are inserted using counter-bore construction, which allows a larger number of balls to be installed than in deep-groove ball bearings.
Single-row angular contact ball bearings can sustain radial, axial and momentary loads. However, any axial load must be applied in one direction. Due to their design, angular contact bearings will experience some amount of axial loading from any radial load that is applied. For this reason, they are often used in pairs.

We provide various combinations with pre-adjusted clearance to simplify assembly.

Typical applications: Speed reducers, automotive applications, construction equipment, pumps, printing presses, paper mill machinery.
