Brand:STNC
Model:TG2521-08M
Send Inquiry
MODEL:TG2521-08M
| Model | TG2521-08M |
| Type | 5 Port/2 Position |
| Pipe Size | G1/2 |
| Nominal Diameter | 4.5 mm |
| Applicable Medium | Air |
| Pressure Range | 0.15~0.8MPa |
| Action | Internally Piloted |
| Max Action Frequency | 5 Cycles/Sec |
| Lubrication | Not Required |
| Voltage Range | ±10% |
| Activating Time | 0.05 Sec |
| Power | AC:5.6VA DC:4W |
| Insulation | Class B |
| Protection | IP 65 |
about Shippment
-
For order value less than usd 2000, we will make the delivery by express
-
For order value more than usd 2000, we can make the deliery as your request
-
All ports are produced by our factory
-
O-ring are from Japan
-
Coil is high temperature resistant
-
Guarantee for long lefetime
-
Guarantee for short delivery time
-
Free sample will be supplied for testing
