| Standard or Nonstandard: | Standard | Structure: | Gate valves | Pressure: | Normal and high |
| Power: | Manual | Material: | Casting | Temperature of medium | Medium |
| Media: | base | Port size: | DN50-DN600 | Place of origin: | Hebei,China |
| Model number: | Z41H-16C | Brand Name: | SHANGHAN | Nominal pressure(Mpa) | 1.6 |
| Testing pressure strength(water)(Mpa) | 2.4 | Testing pressure enclose(water)(Mpa) | 1.76 | Suitable medium | Water,oil,vapor |
| Suitable temperature | ≤425°C | Color: | Grey,silver,white etc | | |
| Suitable market | Russia Ukraine Belarus Uzbekistan Tajikistan | ||||
| Packing: | Woven bags wooden cases containers | ||||
| Delivery time | based on quantity,usually 7-20 days | ||||
| MOQ:1PCS | 1PCS | ||||
| Product Function and Specification of Angle Valve | |||||
| Type | Nominal pressure(Mpa) | Test pressure(Mpa) | Suitable temperature(°C) | Suitable medium | |
| Strength(water) | Enclose(water) | ||||
| Z41H-16C | 1.6 | 2.4 | 1.76 | ≤425 | Water,oil,vapor |
| Product Outline & Connecting Messurement of Angle Valve | |||||||||||
| Type | Nominal diameter DN(mm) | Measurement(mm) | Reference weight(KG) | ||||||||
| L | D | D1 | D2 | b-f | Z×d | H | H1 | D0 | |||
| Z41H-16C | 50 | 180 | 160 | 125 | 100 | 16-3 | 4×18 | 285 | 340 | 180 | 12.7 |
| 80 | 210 | 195 | 160 | 133 | 18-3 | 4×18 | 337 | 419 | 215 | 20.5 | |
| 100 | 230 | 215 | 180 | 158 | 20-3 | 8×18 | 383 | 486 | 245 | 27 | |
| 150 | 280 | 280 | 240 | 212 | 24-3 | 8×22 | 522 | 665 | 275 | 52 | |
| 200 | 330 | 335 | 295 | 268 | 26-3 | 12×22 | 647 | 836 | 300 | 80 | |
| 250 | 450 | 405 | 355 | 320 | 28-2 | 12×26 | 815 | 1090 | 450 | 119 | |
| 300 | 500 | 460 | 410 | 370 | 28-2 | 12×26 | 886 | 1138 | 450 | 156 | |
| 450 | 600 | 580 | 525 | 480 | 32-2 | 12×30 | 1241 | 1604 | 500 | | |
| Advantage of Angle Valve |
| 1,Professional in Standard Carbon Steel Gate Valves |
| 2,Free sample |
| 3,Factory quality certificate ISO9001 & 14001 |
| 4,We are factory for the Russian standard flanged pn16 stem gate valve,casting,machining,painting,delivery process are completed. |
| 5,OEM service is accepted,Customer's logo or label accepted |
| 6,Delivery on time once we accept your order |
| 7,CNC lathe in the workshop with 8 machining assembly line |
| 8,Resin and coated sand casting technology owned by ourselves |
| 9,We have the IF electric furnace support the casting parts for the russian standard stem gate valve. |
| 10,Heat treatment equipment to ensure the valve quality, must will no any deformation on valve body. |
| 11,Twice strict water pressure test and air pressure test before the valve been put in storage and before delivery |
| 12,Middle and high class products to support the customers' different requirement. (light and pound grade) |
| 13,Packing & transporation changed according to your request |
| 14,Produce the products according to your drawings that will be most satisfy you |
| 15,We buy material and make the cast parts by ourselves,control the stem gate valve price and producing progress |
