pallet truck,table truck and forklifts
2016-10-24 14:03 Views:116
Price:Negotiable
Brand:MATERIAL HANDLING EQUIP.Caterpillar
Model:WT-E3000
Send Inquiry
Product Description | Hand-hydraulic Drive Mold table truck with conveyor |
Model | WT-H3000(Non-standard type) |
Rated Lifting weight | 3000.00kg |
Max. Lifting Height | 1400.00mm |
Min. Table Height | 650.00mm |
Wheel Dia. | 300.00mm(Front Wheel) 180.00mm(Rear wheel) |
Lifting power supply | Handhold pump(Lifting by hand-hydraulic power) |
Overall Dimension | 2450x1000mmX780mm |
Price | |
Lead time | |
Validity | |
Product Description | Full-Electric Mold table truck with conveyor |
Model | WT-E2500(Non-standard type) |
Rated Lifting weight | 2500.00kg |
Max. Lifting Height | 1350.00mm |
Min. Table Height | 400.00mm |
Overall Dimension(LxW) | 2150x1000MM stand pedal folded,2650x1000MM stand pedal un-folded |
Table and structure size（LxW） | 2000MMx850MM |
Equipment Configuration | l imported DC Driving Wheel 1200W l Swiss BUCHER pump assembly 2200W l American CURTIS Electrical Control system l Italyhydraulic cylinder l JapanNOK Sealing l Chinese 24V210AH Traction Storage Battery, External Electric Charger |
Price | |
Lead time | |
Validity | Power type ................................................................................................................................Diesel
Rated Capacity (kg) ………………………………….............................................................3000/3500
Load Center (mm)..........................................................................................................................500
Sta. Lift Height (mm)...................................................................................................................3000
Sta. Free Lift (mm).........................................................................................................................164
Forks (mm).....................................................................................................................1070*125*45
Tilting Angle (deg)........................................................................................................................6/12
Turning Radius (mm) …………………………………...........................................................2460/2520
Min.Right Angle Stacking Aisle..........................................................................................4155/4220
Max. Driving Speed (load/unload)（km/h）..............................................................................20/20
Max. Lifting Speed (load/unload)（mm/s）…………………………………................400/420,380/400
Max. grade ability (%)......................................................................................................................20
Front overhang(mm)......................................................................................................................483
Rear overhang(mm) ……… …………………………..............................................................522/580
Service weight(kg) …………………………………...............................................................4300/4700
Thread (front/rear)(mm)........................................................................................................1000/980
Wheel base(mm)..........................................................................................................................1700 Dimension
Length, with Sta. Fork (mm) FD30, FD30T/FD35, FD35T.................................................3770/3830
Width (mm)..................................................................................................................................1238
Mast Height, Lowered (mm)........................................................................................................2075
Height, overhead guard (mm) FD30, FD30T/FD35, FD35T.......................................................2100 Ground clearance
Mast(mm).......................................................................................................................................132
Middle of wheel base(mm).............................................................................................................165 |
