cast steel bevel gear gate valve, flange ends, gear operation.
Design & manufacture standard: API6D, API600, API603, ISO10434.
Face to face dimensions: ANSI/ASME B16.10.
Flange connection: ANSI/ASME B16.5 for NPS≦24〞, ASME B16.47A/MSS SP-44 for NPS>24〞.
Butt-welding end dimensions: ANSI/ASME B16.25.
Socket-welding dimensions: ANSI/ASME B16.11.
Inspection & test standard: API6D, API598.
Pressure: 150Lb, 300Lb, 600Lb, 900Lb or PN 2.0MPa~PN 15.0MPa or JIS 10K, 20K.
Nominal diameters: 2〞~ 24〞or DN50~DN600.
Major materials: WCB, WC1, WC6, WC9, A105, CF8(304), CF8M(316), CF3(304L), CF3M(316L), etc.
Driving styles: manual/electric/conical gear/pneumatic, etc.
