Model:HR-88
Send Inquiry
1.Silver coating
2.The closing and latching speed can be adjusted.
3.Function of back check and time delay .
Max load: | 40-65kg 60-85kg |
Max door width: | ≤1500MM |
Drive arm thickness: | 3.0~8.0MM |
Drive arm length: | 130~400MM |
Drive arm width: | 18~24mm |
BOX Size: | 28.5*20.5*10MM |
Materail: | Iron |
Warranty: | 1 million cycle |
Drive arm:245mm
Bolt:185mm
Bush:155mm
Triangle Bracket:70mm
1.Drive arm:
Thickness Range: 5.0 (3.0~8.0mm optional)
Width Range: 20mm (18~24mm optional)
The dimensions of bolt&bushing should be consistent with drive arm
2. Adjustable closing speed: 180°—15°
3. Adjustable closing and locking through hydraulic: 15°—0°
4. Colors: Silver
5. For single-action door leaf
6. For either left or right closing doors
