Ground Turnover Cutting Machine
I. Overview
Ground Turnover Cutter was developed and used widely in China. based on the cutter improved by Kehai company, we made further progress according to service condition of our customers and realized further advantages of the cutter.
II. Working Mode
The prestreamed body is lifted by the pointed traveller to the turnover table and stripping the die grid and turned for 90° by hydraulic unit, and then making sixway cutting by the longitudinal and transverse units. After cutting the body is turned for 90° by the hydraulic unit to the original positon, finishing a cutting period.
III. Main Characteristics
1. Short cutting steel wire, high cutting accuracy.
2. The unsticky streamed blocks are much more convenient for producing aerated-sand blocks.
3. It can produce panel, needn't panel severing machine.
4. The rejected cutting material can be reclaimed, no waste of streamed blocks.
5. Easy operation and control with automatic control.
| No. | Size | Size Before cutting(mm) | Cutting Cycle | Cutting Ability(m3/year) | Six-side Cutting Precision(mm) | Total Power(kw) | Dimension(mm) |
| 1 | 4.2m | 4250*1240*650 | Block6-8minutes | Over 100000 | ≤±3.1.1 | 25.5 | 12200*4200*5600 |
| 2 | 4.8m | 4860*1560*650 | Block6-8minutes | Over 200000 | ≤±3.1.1 | 30 | 16000*6000*5500 |
| 3 | 6m | 6050*1540*650 | Block6-8minutes | Over 200000 | ≤±3.1.1 | 30 | 18500*6000*5800 |
