LPGFM1 Flow Meter LPGFM1 Flow Meter is designed with international advanced standards based on customers requirements. It is using cast iron body,stainless steel cylinder liner,and four-pistoned construction with check valve inlet, high strength,high wearability ,and high accuracy, long service lift . it can be used for gasoline, diesel, kerosene or compound of them. 2. Working Principle: Petroleum flows out of pump flows into flow meter, it causes a angular deviation to the flow meter transmission shaft, and the pulse generating gadget gives out pulse signal to indicate the volume of the liquid. 3. Technical Specification: Max working pressure：1.8Mpa.Flow Rate: 5-50LDischarge rate of each revolution:0.5L/rAdjustable minimum volume: 0.1%Accuracy: ±0.3% Repeatable Tolerance: ≤ 0.15% package: 1 pc/ wooden case Net weight :30kgsGross weight:31kgs.Dimension :300mm*315mm*360mm
