KSP Series: ISO 16028 Flush Face Coupling Interchange

1. Material: Steel

2. Spring: SS304

3. Back-Up Ring: Teflon

4. Seal: Standard Buna-N  -25centidegree + 125centidegree

5. Locking Sleeve type: Option & On Requested

6. Finish:Zinc plated with yellow chromate finish

Interchange Standard

Parker FE     Safeway S56      Faster2FFI

Aeroquip FD 89      Snap Tite 74      Dnp PLT4

Tomco FE       Stucchi FIRG

Features

1. KSP Series couplings provide non-spill connection/disconnection for general purpose applications.

2. Dimensionally interchangable with ISO16028 standard flush face couplings.

3. Wide selection of body sizes,ranging from 1/ 4" to 2" to provide versatility in a variety of applications.

4. Sealed spring cavity prevents dust collection and possible sleeve binding.

5. Heat treated valve sleeve and poppet resist scratches and wear.

6. Crimped valve seal prevents seal washout.

7. Hardened locking collar sleeve resists brinelling,avoids cracking and provides longer life.

8. Large number of locking balls resists brinelling.

9. Concealed lock ring prevents accidental removal.

10. Zinc plate with yellow chromate finish resists corrosion.

11. Positive lock retaining ring will not wash out under high flow conditions.

12. Induction hardened locking surface reduces wear and brinelling.
