Model:SP-L, SP-M, SP-H, SP-I
Slew drives are used for concurrent transmission of axial and radial forces, as well as transmission of tilting moments. Slew drives consist of a ball or roller slewing ring, hydraulic or electric drives, and a completely enclosed housing. Series SP slew drives are designed with spur gear and straight toothing.
The SP slew drive is powered by a pinion gear unit.
Typical applications:
Handling and automation equipment, packaging machines, tool changers, grippers, construction machines, land and forestry machines
Characteristics:
Enables higher output rotary speeds
Very narrow in size around the Slewing Ring, but the drive is broad in axial direction
Offers a large, open internal diameter
Very suitable for upper structures with larger radial diameters
Basically not self-locking in design
Can be equipped with locking brakes
The position of output shaft is insignificant
Preferred design for vibration and impact loading applications
SP-L 0311, SP-L 0411, SP-L 0541, SP-L 0641, SP-L 0741, SP-L 0841, SP-L 0941, SP-L 1091, SP-I 0229, SP-I 0411, SP-I 0541, SP-I 0641, SP-M 0311, SP-M 0411, SP-M 0541, SP-M 0641, SP-M 0741, SP-M 0841, SP-M 0941, SP-M 1091, SP-H 0455, SP-H 0555, SP-H 0655, SP-H 0755, SP-H 0855, SP-H 0955
