Model:ML2200,ML2000,ML720,ML1200 ,and so on
Send Inquiry
Feature:
- Sliding bearing employed cast copper alloy steel and so less wear off and less shaking.
- Fly wheel has a big moment and greater cutting annd pressing force.
- Machine body is made of top cast iron and so high intensity and good rigidity.
- single disc clutch and agile and reliable.
- It has 3 functions: single sheet, continuous and delayed opening. The delay time is adjustable.
- Operation height is reasonable. Pressing frame's open angle is big.
- Safety protection system is reliable.
Key technical parameter:
| Model | Valid area | Speed | Max knife length | Motor power | Weight | Dimensions L/W/H |
| ML2200 | 2200x1400mm | 162 s/m | <64m | 15kw | 22000kg | 2530x3400x2300mm |
| ML2000 | 2000x1400mm | 162 s/m | <58m | 15kw | 16500kg | 2270x3100x2150mm |
| ML1800A | 1800x1400mm | 162 s/m | <52m | 11kw | 13500kg | 2240x2800x2130mm |
| ML1600 | 1600x1200mm | 162 s/m | <43m | 7.5kw | 11500kg | 2170x2560x2230mm |
| ML1500A | 1500x1100mm | 172 s/m | <40m | 7.5kw | 8200kg | 2010x2480x1960mm |
| ML1500 | 1500x1050mm | 172 s/m | <40m | 7.5kw | 8000kg | 2010x2400x1930mm |
| ML1400 | 1400x1000mm | 172 s/m | <38m | 5.5kw | 7200kg | 2010x2400x1930mm |
| ML1300 | 1300x920mm | 182 s/m | <38m | 5.5kw | 6500kg | 1920x2140x1800mm |
| ML1200 | 1200x850mm | 182 s/m | <32m | 4kw | 4800kg | 2000x2000x2000mm |
| ML1100 | 1100x800mm | 202 s/m | <30m | 4kw | 4500kg | 1900x1780x1700mm |
| ML720 | 750x520mm | 252 s/m | <15m | 2.2kw | 1700kg | 1260x1350x1280mm |
| PYQ203C | 930x670mm | 232 s/m | <25m | 4kw | 3000kg | 1670x1670x1630mm |
