Model:LNE-VH
Send Inquiry
Product code: LNE-VH
Product material: PA(polyamide)
Working temperature: -40~+110℃
Color: Black. Other colors are customizable
Variety available: two types available for selection: with lid and without lid
Property: LNE-VH type bracket is the fitting of flexible pipes, used for securing the flexible pipes or cables, etc.
| Item No. | Suitable flexible pipe | B(mm) | H(mm) | T(mm) | M(mm) | A(mm) |
|---|---|---|---|---|---|---|
| LNE-VH-10.0 | AD10.0 | 30 | 23 | 12.5 | 4 | 6.5 |
| LNE-VH-13.0 | AD13.0 | 30 | 23 | 12.5 | 4 | 6.5 |
| LNE-VH-15.8 | AD15.8 | 30 | 23 | 12.5 | 4 | 6.5 |
| LNE-VH-18.5 | AD18.5 | 35 | 30 | 15.0 | 5 | 6.5 |
| LNE-VH-21.2 | AD21.2 | 35 | 30 | 15.0 | 5 | 6.5 |
| LNE-VH-28.5 | AD28.5 | 42 | 38 | 16.0 | 6 | 11.5 |
| LNE-VH-34.5 | AD34.5 | 51 | 43 | 16.0 | 6 | 11.5 |
| LNE-VH-42.5 | AD42.5 | 61 | 51 | 16.0 | 6 | 11.5 |
| LNE-VH-54.5 | AD54.5 | 74 | 64 | 19.0 | 6 | 11.5 |
