Model:TYF-116
Send Inquiry
| TYF-116 | ||||
| Injection Unit | A | B | C | |
| Screw Diameter | mm | 35 | 38 | 42 |
| Screw L/D Ratio | L/D | 22.8 | 21 | 19 |
| Injection Capacity Theory | cm3 | 154 | 181 | 222 |
| Injection Weight | g | 143 | 168 | 206 |
| Injection Pressure | Mpa | 219 | 185 | 219 |
| Injection Rate | g/s | 71 | 85 | 101 |
| Platicizing Capacity | g/s | 12 | 15 | 17 |
| Screw Speed | rpm | 200 | ||
| Clamping Unit | ||||
| Clamping Force | Kn | 960 | ||
| Moving mould-plate stroke | mm | 315 | ||
| Max.mould height | mm | 360 | ||
| Min. mould height | mm | 150 | ||
| Space between tie-bars | mm | 360x340 | ||
| Hydraulic Ejector Force | Kn | 43 | ||
| Hydraulic Ejector Stroke | mm | 90 | ||
| Ejector Number | n | 5 | ||
| Other | ||||
| Pump Prssure | Mpa | 16 | ||
| Motor Power | Kw | 11 | ||
| Heating Capacity | Kw | 6.9 | ||
| Machine Dimension | m | 4.16X1.19X1.79 | ||
| Machine Weight | t | 3.2 |
