Hard Metric Female
2016-10-25 10:42  Views:230
Price:Negotiable
Send Inquiry

1)HMF-A22230-C01
Hard Metric Female with Shield Product, gold plating 30u'
2)HMF-A22230-C02
Hard Metric Female without Shield Product, gold plating
30u'

Notes:
1.Technica specification characteristic:
A. Current Rating:1.0A at 70'
B. Terminal Contact Resistance: 20mΩMax
C. Voltage Current: 750V AC 1min
D. Insulation Resistance:10000MΩ Min at DC 500V

2.Materials;
A.Terminal: Phosphor Bronze Local Plating Gold30u'
B.Plastic Thermoplastic: PBT + 30%GF UL 94V-0

3.Temperature Range: -55? to 125?
