DIN 3352-F4 Cast Iron Gate Valve(Non Rising Stem)
2016-10-25 10:45  Views:189
Price:Negotiable
Model:DIN 3352-F4
Send Inquiry

Application of Gate Valve

1Face to face is according to DIN 3302
2Flange drillef is acording to DIN 2532/2533




Test of Gate Valve
Workingpressure  PNlO PN16
TestpressureShell21.1kgf/cm²24kgf/cm²
Seat15kgf/cm² 17.6kgf/cm²





Components of Gate Valve
1BodyCast iron or Ductile iron
2Seatring Cast bronze/Stainless steeI(B62/SS304)
3DiscCast iron or Ductile iron
4StemStainless steel
5BopnnetCast iron or Ductile iron
6PackingNot asbestos
7Gland Ductile iron
8Handwheel Cast iron or Ductile iron












Dimensions of Gate Valve
DN40506580100125150200250300350400
1.5"2"2.5"3"4"5"6"8"10"12"14"16"
L140150170180190200210230250270290310
H212236262292336400438552668714805917
D(PNlO)150165185200220250285340395445505565
D(PN16)150165185200220250285340405460520580
