Angular Contact Ball Bearing

Angular contact ball bearings are able to support radial load and axial load. As single row angular contact ball bearings can only support axial load in single direction, matched bearing mounting is often adopted to them. As matched pair of bearings, preload for them is more convenient. Retainer are made of brass, synthetic resins or others subject to individual bearing features and application conditions.

1).Main structure

A. single-row angular contac ball bearing

    single-row angular contac ball bearing have separable and non-separable designs,such as S7000 series and SN7000 series.

B. double-row angular contact ball bearing.

C. paired and match angular contact ball bearing.

2). Allowed angle of inclinnation

2). Tolerance and clearance
