Model:MM52130Z
Send Inquiry
The machine belongs to powerful calibrating sanding machine, mainly used for the calibrating sanding and surface polishing of laminated wood, solid wood, composite floor board, plywood and so on.
| Model | MMR51130Z | MMU51130Z | MM52130Z | MM53130Z |
| Working width | 1300mm | 1300mm | 1300mm | 1300mm |
| Working height | 120mm | 120mm | 120mm | 120mm |
| Main motor | 30KW(40HP) | 22KW | 30,22KW(40,30P) | 30,22,18.5KW(40,30,25HP) |
| Feed motor | 2.2KW(3HP) | 2.2KW(3HP) | 4KW(5HP) | 5.5KW(7.5HP) |
| Table hoist motor | 0.55KW(3/4HP) | 0.55KW(3/4HP) | 0.55KW(3/4HP) | 0.55KW(3/4HP) |
| Feed speeds | 5-20m/min | 5-20 m/min | 5.5-27.5 m/min | 5.5-27.5 m/min |
| Sanding belt size | 1330× 2200mm | 1330× 2200mm | 1330× 2200mm | 1330× 2200mm |
| Working air pressure | 0.5Mpa | 0.5Mpa | 0.5Mpa | 0.5Mpa |
| Exhaust air consumption | 5000m 3 /h | 4000 m 3 /h | 9000 m 3 /h | 13000 m 3 /h |
| Overall dimensions | 1730x2640X2120MM | 1730x2640X2120MM | 2120x2640X2120MM | 2570x2640X2120MM |
| Net weight | 2380kg | 2380kg | 3800kg | 4940 kg |
| Model | MMR51130 | MMU51130 | MM52130 | MM53130 |
| Working width | 1300mm | 1300mm | 1300mm | 1300mm |
| Working height | 120mm | 120mm | 120mm | 120mm |
| Main motor | 22KW(40HP) | 18.5KW | 22,18.5KW(30,25P) | 22,18.5,15KW(30,25,20HP) |
| Feed motor | 1.5KW(2HP) | 1.5KW(2HP) | 3KW(5HP) | 4KW(5HP) |
| Table hoist motor | 0.55KW(3/4HP) | 0.55KW(3/4HP) | 0.55KW(3/4HP) | 0.55KW(3/4HP) |
| Feed speeds | 5-20m/min | 5-20 m/min | 5-20 m/min | 5-20 m/min |
| Sanding belt size | 1330× 2200mm | 1330× 2200mm | 1330× 2200mm | 1330× 2200mm |
| Working air pressure | 0.5Mpa | 0.5Mpa | 0.5Mpa | 0.5Mpa |
| Exhaust air consumption | 400m 3 /h | 300 m 3 /h | 700 m 3 /h | 1000 m 3 /h |
| Overall dimensions | 1870x1980X2150MM | 1870x1980X2150MM | 2220x1980X2150MM | 2720x1980X2150MM |
| Net weight | 2000 kg | 2000 kg | 3200 kg | 4160 kg |
