Summary

This machine is suitable for packing tea fannings, tea bag , tea , Herb-tea and different shape tea from foodstuff industry.

Introduction

Cylinder series is our factory new model manufacture development equipment. Use automation cylinder down-pressure sealing principles , double location operation Independent. adjust heat pressing time freely and strong utility, the machine use advanced automatic numerical control thermostat technology, stable property, high thermal efficiency , Long life, low power consumption, less noise . used 220V power whole machine adopts all stainless steel . bright and clean , original paper cup separation technique for prevent adhesion of finished good tea cup and heat pressing head, operation more convenient and practical.

Main technical parameter :

Machine adopt new type round filter pape rand mesh round filter paper ( thickness 18 grams , Diameter :77mm) , Paper cup specification :6-30 oz and others ;

Raw material : tea fannings , tea bag , tea , Herb-tea and fruit tea, coffee milk-tea and different shape tea .

Power supply : 220V 50 Hz

 total power :0.3kw

Rating Capacity : 650 cups / hour by one worker , 1300 cups/hour by two worker .

Overall dimention (LxWxH):1300x400x1500mm

Total weight :58kg

Heat pressing temperture : 225°C (can control)

heat pressing time per cup :1.5 second ,

Temperature control precision : ±5°C

air compressor allocation : 2HP air pressure: 0.6Mpa
