Model:dia:6-20mm
PDC（Polycrystalline Diamond Compact）cutter bit inserts are sintered with selected diamond powder and tungsten carbide under high temperature and ultra-high pressure, PDC cutters have high hardness, abrasion resistance and impact resistance, are widely used for oil/gas drill bit, rock drill and coal mining drill bit，also could be used for diamond tools for cutting, grinding, polishing.
Our PDC cutter included three series:
A.PDC cutter used in oil/gas drilling,
B.PDC cutter used in geology exploration, rock drilling and mining
C.PDC/PCD cutter used in grinding and polishing
Specifications | 0808 | 1004 | 1008 | 1304 | 1308 | 1313 | 1608 | 1613 | 1616 | 1908 | 1913 | 1916 | 1919 |
Diameter(mm) | 8.20 | 10.00 | 10.00 | 13.30 | 13.44 | 13.44 | 16.00 | 16.00 | 16.00 | 19.05 | 19.05 | 19.05 | 19.05 |
Height( mm) | 8.00 | 4.00 | 8.00 | 4.50 | 8.00 | 13.20 | 8.00 | 13.20 | 16.00 | 8.00 | 13.20 | 16.00 | 19.00 |
