Jinan Fast CNC Machinery Co., Ltd. is a professional manufacturer and exporter of CNC machines in China for many years.

We have exported our cnc machines to Russia,India,Indonesia,Jordan and so on.

CNC Hydraulic Plate Punching& Drilling Machine CJ100/CJZ100 :

The movements in X and Y axes are controlled by servo motor and lead ball screw. The punching position is controlled by biaxial NC controlling system. The processing data can be input into the controlling system and disolyed on CRT screen.

Model: CJ100
1. Punching force(kN): 1000
2. Printing force(kN): 800
3. Thickness range of workpiece(mm): 6-25
4. Max. Workpiece dimension(mm): 1500*800
5. Number of station: 3
6. Max. Pinching diameter(mm): 31.5
7. Min. Margin distance from punching center(mm. Punching diameter 25.5): 25
8. Number of letter(mm): 14or 18
9. Size of letter(mm): 14*10
10. Working accuracy: GB2694-81
11. Overall dimension(mm. FR*LR*-H)3020*2522*1875

GB/T19001-2000 ---- ISO9001: 2000

On request, CJ100 machine can also be equipped with drilling unit, which is model

CJZ100, whose technical data are as follows:

Model
 CJZ100

Max. Drilling thickness
 40 mm

Max. Drilling diameter
 50 mm

Speed of main spindle
 100-750 r/min

Feeding speed of main spindle
 20-280 mm/min

Stroke of main spindle
 180 mm

 Power of main spindle
 5.5 KW


Technical Charecteristics:
1. Integrated machine with machanical, electrical and hydraulic systems;
2. PLC control and servo-motor feed-in;
3. Self-diagnostic function;
4. Easy programming and connectable with data generated directly from copying the specimen.

Advantages:
1. Modular assembling for main functional parts, easy maintenance;
2. Punching, printing and drilling operations on one plate;
3. Efficient drilling operation by fast approach, slow working and fast return program;
4. On programming, either input punching diameter, location and quantity of workpiece, or network locally with design department to interchange data base;
5. Constant workpiece accuracy and good operating condition.

For details, pls inquiry at mail: jinanfast AT yahoo.com.cn ;  We welcome any inquiry and questions.
