TD15

Material

Pitch:8.0mm
Poles:1P-NP
Screw:M3,Ni-plated steel
Terminal:Tin-plated brass/steel
Housing:PA66.UL94V-0

Electrical

Rated voltage:660V
Rated current:15A
Withstanding voltage:AC2000V/1Min
Wire range:22-14AWG

Mechanical

Temperature range:-40deg to +105deg
Max torque:8kg.cm
