Delivery Time:7 days

Beam Sensor>Photoelectric Beam Sensor CX-BL

Model: CX-BL

Photoelectric Beam SensorCX-BL>Brief Description

1.Have IP85 Protection Grade and DSP Chip
2.Beams: 6
3.With DSP chip
4.Optical source: digital infrared pulse ?

Photoelectric Beam SensorCX-BL>Key Specifications/Special Features:

With DSP chip

Protection grade: IP85

Outdoor distance: 50, 100, 150, 200, and 250m

Indoor distance: 150, 300, 450, 600, and 750m

Beams: 6

Optical source: digital infrared pulse

Response speed: 50 to 700ms

Alarm output common: NC and no contact capacitor 30V AC/DC/0.5mA

Alarm output bus: MA bus across wave carrier model

Voltage: DC 9 to 24V AC/11 to 18V

Current: 60 and 80mA

Operating temperature: -25 to 60°C

Humidity: 5 to 95%

Horizontal adjustment axis: 360°

Vertical adjustment axis: ±10°

Tamper output: normal close (NC) touching capability 24V AC/DC/0.5mA

Visibility: ≥5m

Housing material: polycarbonate
