hydraulic SAI piston motor GM series
2016-10-25 12:47  Views:292
Price:Negotiable
Model:GM05-GM9
Send Inquiry

hydraulic SAI piston motor GM sereis, widely applied in hydraulic and transmission systems of plastics machinery, light industrial machinery, heavy type metallurgical machinery, petroleum and coal mining machinery, lifting and transportation equipment, ship's deck machinery, geological prospecting equipments, etc.

Features of hydraulic piston motor:
1. High Efficiency, small volume, light weight
2. High starting torque, high specific speed range
3. Motor can be used in the pump working condition and realize freewheel operation condition.
4. Compact structure, reasonable design
5. Adopting high load capacity bearing and output shaft which can bear radial load and reverse the direction of rotation.
6. The mounting dimension and more than 80% of internal components can be interchanged with SAI Products.



Technical Performance Data of GM **----** Series Hydraulic Motors

   Type


Displacement (ml/r)

Rated Pressure (MPa)

Peak  Pressure (MPa)

Rated  torque (N.m)

Specific  Torque (N.m/MPa)

Continual  Speed

Max  Speed

Weight   (Kg)

(r/min)

GM05-60

59

25

45

235

9.4

1 ~ 700

1000

22

GM05-75

74

25

42.5

295

11.8

1~700

1000

GM05-90

86

25

37.5

343

13.7

1 ~ 700

1000

GM05-110

115

25

40

458

18.3

1 ~ 650

900

GM05-130

129

25

37.5

513

20

1 ~ 650

900

GM05-150

151

25

32.5

600

24

1 ~ 650

900

GM05-170

166

25

32.5

660

26.4

1 ~ 600

800

GM05-200

191

25

28

760

30.4

1 ~ 600

800

GM1-100

99

25

42.5

385

15.4

1 ~ 550

1000

31

GM1-150

154

25

40

600

24

1 ~ 550

1000

GM1-175

172

25

37.5

670

26.8

1 ~ 550

900

GM1-200

201

25

35

785

31.4

1 ~ 550

800

GM1-250

243

25

35

950

38

1 ~ 450

700

GM1-300

290

25

30

1130

45.2

1 ~ 350

650

GM1-320

314

25

28

1225

49

1 ~ 350

600

GM2-200

192

25

42.5

750

30

0.7 ~ 550

800

51

GM2-250

251

25

42.5

980

39.2

0.7 ~ 550

800

GM2-300

304

25

40

1188

47.5

0.7 ~ 500

750

GM2-350

347

25

37.5

1355

54.2

0.7 ~ 500

750

GM2-420

425

25

35

1658

66.3

0.7 ~450

750

GM2-500

493

25

35

1923

76.9

0.7 ~ 450

700

GM2-600

565

25

30

2208

88.3 0.7 ~ 450

700
