T grid:
1. The standard sizes see the chart below .
2. We can produce to customers specifications as below :
- Raw materials : ZINC coating from 80 to 275 gram per square meter , also can use the stainless steel mirror or aluminum mirror .
- Thickness : Form 0.25mm to 0.40mm .
- Dimension :
Length : Main Tee up to 3.75 meters ,Cross Tee up to 1.22 meters ,
Width : From 14mm to 24mm and Hight from 24mm to 38mm .
We can produce any size to meet and install your ceiling .
- Colour : The surface is white , but also can be stainless steel mirror and aluminum mirror .
STANDARD SIZE FOR FLAT SURFACE T GRID SYSTEM |
| ||||
|
|
|
|
|
|
Item | Description | Width (mm) | Hight (mm) | Thickness (mm) | Length |
1 | T24 MAIN TEE | 24 | 38 | 0.25~0.40mm | up to 3.75 meters |
32 | 0.25~0.40mm | up to 3.75 meters | |||
28 | 0.25~0.40mm | up to 3.75 meters | |||
26 | 0.25~0.40mm | up to 3.75 meters | |||
24 | 0.25~0.40mm | up to 3.75 meters | |||
T24 CROSS TEE | 24 | 38 | 0.25~0.40mm | up to 1.22mmm | |
32 | 0.25~0.40mm | up to 1.22mmm | |||
28 | 0.25~0.40mm | up to 1.22mmm | |||
26 | 0.25~0.40mm | up to 1.22mmm | |||
24 | 0.25~0.40mm | up to 1.22mmm | |||
2 | T15 MAIN TEE | 15 | 38 | 0.25~0.40mm | up to 3.75 meters |
32 | 0.25~0.40mm | up to 3.75 meters | |||
28 | 0.25~0.40mm | up to 3.75 meters | |||
26 | 0.25~0.40mm | up to 3.75 meters | |||
T15 CROSS TEE | 15 | 38 | 0.25~0.40mm | up to 1.22mmm | |
32 | 0.25~0.40mm | up to 1.22mmm | |||
28 | 0.25~0.40mm | up to 1.22mmm | |||
26 | 0.25~0.40mm | up to 1.22mmm | |||
3 | T14 MAIN TEE | 14 | 32 | 0.25~0.40mm | up to 3.75 meters |
28 | 0.25~0.40mm | up to 3.75 meters | |||
24 | 0.25~0.40mm | up to 3.75 meters | |||
T14 CROSS TEE | 14 | 32 | 0.25~0.40mm | up to 1.22mmm | |
28 | 0.25~0.40mm | up to 1.22mmm | |||
24 | 0.25~0.40mm | up to 1.22mmm | |||
