Description:The injector rail, controlled by the ECU, injects gas directly into each cylinder. The injection solenoid valves are mounted on a modular common rail in aluminium. This modular system permits to be suitable to all kind of engine from 2 to 8 cylinders.Type: injection solenoid valves on modular common railDimensions (for 4 cylinders version): L110 x H70 x D40mmWorking pressure: 0.8 - 2.5 barsGas inlet: brass a 10.5mm diameterOutlet nozzles: steel nozzle with outlet diameter of 2.1, 2.3, 2.5 or 2.7mmCoil: 6 ohm coil with metallic coverVibration limiter pivot: silent block 6mm diameter
