4-color pad printing with Conveyor
2016-10-25 15:55 Views:143
Price:Negotiable
Model:SPM4-150/16
Send Inquiry
| Payment Terms | T/T. LC DA | | Packing | Wooden case | | Lead Time | Within 4 days | | Standards Certificate | ISO9001-2000 | | Power Supply | 110/220v 60/50Hz -I Phase | | Colour Painted | Green | | Specifications | SPM4-150/16 Four-colour open inkwell pad printer with conveyer:
1.Max. plate size: 100×150mm
2.Max Printing area: 85×130mm;
3.Max. worktable area: 90×125mm
4.Max. printing speed: 1200pcs/h
5.Printable colours:4
6.Stroke of cylinder up-down: 80mm;
7. Stroke of table shuttle: 125mm;
8. Range of table height adjustment: 250m.
SPM4-200/16 Four-colour open inkwell pad printer with conveyer:
1.Max. plate size: 100×200mm
2.Max Printing area: 85×170mm;
3.Max. worktable area: 90×125mm
4.Max. printing speed: 1200pcs/h
5.Printable colours:4
6.Stroke of cylinder up-down: 80mm;
7. Stroke of table shuttle: 125mm;
8. Range of table height adjustment: 250m.
SPM4-250/16 Four-colour open inkwell pad printer with conveyer:
1.Max. plate size: 100×250mm
2.Max Printing area: 85×220mm;
3.Max. worktable area: 90×125mm
4.Max. printing speed: 1200pcs/h
5.Printable colours:4
6.Stroke of cylinder up-down: 80mm;
7. Stroke of table shuttle: 125mm;
8. Range of table height adjustment: 250m. | | Advantages | 1.Total microcomputer controlled operation;
2.Auto four digit counter built-in;
3.Ink covering by ink roller ;
4.Fully coin aluminum structure which is sturdy and long life
5.Independent pad stroke and speed control;
6.Printing speed adjustable to meet with different needs;
7."Inking twice, printing once" to get thicker ink covering; | | Machine Fittings | 1. Four Pad plates,
2. Four pads
3. Two blades
4. A tool box. | | Package List | LC-SPM4-150/16
1. Package dimension:1150×840×1410mm
2. Gross weight: 185kg
LC-SPM4-150/16
1. Package dimension:1150×920×1410mm
2. Gross weight: 215kg | | Ship Date | By sea:
within 30 days after receive T/T Or
LC. | | Testing | Please provide:
1. 110V or 220V power supply.
2. 5-7 bar compress air.
3. Etching plate 4 pcs.
4. Fixture 16 pcs.
5. 50 pcs product samples. | | Customer | 1. Precision Advertising Company Limited, (Ghana).
2. Canada
3. Chile |
|
| |
| Pad printer can print four colours one time .With conveyer worktable to ensure higher production efficiency . Coin aluminium structure frame ensure more light and strongly.opened ink to store and coat for simply operation. Overprint Precision and suitable for half-tone design. Widely used in the toys, gifts, plastics package production |
|
