3 pcs floating ball valve, pipeline valve, oil valve.
This kind of valves are especially designed to meet the severe requirements of customers fo long-distance fluid transportation. And they have lots of advantages.
Design & manufacture standard: API6D, API608, ANSI/ASME B16.34, MSS-SP-72
Face to face dimensions: ANSI/ASME B16.10, API6D.
Flange connection: ANSI/ASME B16.5 for NPS≦24〞, ASME B16.47A/MSS SP-44 for NPS>24〞.
Butt-welding end dimensions: ANSI/ASME B16.25.
Inspection & test standard: API598, API6D.
Pressure: 150Lb, 300Lb, 600Lb, 900Lb or PN 2.0MPa~PN 15.0MPa or JIS 10K, 20K.
Nominal diameters: 1/2〞~ 24〞or DN15~DN600.
Major materials: WCB, WC1, WC6, WC9, A105, CF8(304), CF8M(316), CF3(304L), CF3M(316L), etc.
Driving styles: manual/electric/worm wheel/pneumatic, etc.
Fire-resistant & anti-static design.
