Model:YD-5500
YD-5500 6-Cavity Fully Auto-Matic Pet Strech Blow Moulding Machine (2011)
YD-5500 6-Cavity Fully Auto-Matic Pet Strech Blow Moulding Machine (2011)
YUANDA series are the most stable two-step fully-automatic pet stretch-blow moulding machines(preheat). It has two to eight cavities and the maximum capacity of the products is 2L. It can blow bottles in shapes: Carbonated, mineral, pesticide, cosmetics, wide-mouth, hot filling, and other packing containers, which is made of plastic of crystalline type, such as PET and PP etc.
1). High Automatization
2). High Intelligence: The machine can be controlled through touch screen and running status is shown on it.
3). High Quanlity: Steady infrared heating system blowing and highly precise blow-mould closing system ensure quality.
| General Information | YD-900 | YD-1800 | YD-3500 | YD-5500 | ||
| Clamping Force | 150KN | 180KN | 370KN | 565KN | ||
| Clamping Stroke | 120-175MM | 120-175MM | 120-175MM | 80-130mm | ||
| Max. Stretching Stroke | 370MM | 370MM | 370MM | 370mm | ||
| Bottom Moving Stroke | 70MM | 70MM | 70MM | 0-70mm | ||
| Number of Cavities | 1 Cavity | 2 Cavity | 4 Cavity | 6Cavity | ||
| Theoretical Output | 1000 BPH | 2000 BPH | 4000 BPH | 5500BPH | ||
| Max. Mould Thickness | 250MM | 250MM | 250MM | 300mm | ||
| Space Between Tie Bars | 300*380MM | 400*380MM | 640*380MM | 780x380mm | ||
| Electrical System | ||||||
| Voltage Standard | 380v/3PH/50Hz or special order | |||||
| Number of Heating Zone | 2 Sections | 2 Sections | 4 Sections | 4 Sections | ||
| Total Power (Full Loaded) | 20KW | 28KW | 60KW | 75KW | ||
| Container | ||||||
| Max. Container Volume | 6L | 1.5L | 1.5L | 1.5L | ||
| Neck Diameter Range | 16-38mm | 16-38mm | 16-38mm | 16-38mm | ||
| Max. Container Diameter | 110mm | 110mm | 110mm | 110mm | ||
| Max. Container Height | 380mm | 380mm | 380mm | 360mm | ||
| Air system | ||||||
| Low Air compressor | 10Bar | 10Bar | 10Bar | 10Bar | ||
| High Air compressor | 30-40Bar | 30-40Bar | 30-40Bar | 30-40Bar | ||
| Dimension & Weight | ||||||
| Blow molding machine | 2.2*1.5*2.0m | 2.15*1.5*2.0m | 3.55*1.5*2.0m | 4.25*1.5*2.0m | ||
| Preform Autoloader | 1.1*1.2*2.2m | 1.1*1.2*2.2m | 1.1*1.2*2.2m | 1.1*1.2*2.2m | ||
| Net Weight | 1.8T | 2T | 3.5 T | 4T | ||
