Model:GV-01
E1-V.35 Protocol Converter
Item No.: GV-01
Description:
E1-V.35 Protolcol Convertor provide conversion between ITU-T G.703 standard E1 interface and standard V.35/V.24 interface, can convert E1 channel of SDH, PDH, and other Optical Transmission Equipment or microwave, satellite Equipment to V.35/V.24 channel, Extend V.35 channel of DDN. Used widely in data communication networks, Connecting with V.35/V.24 interface of Routers and Optical Transmission Equipments without G.703 interface, realize match between different network equipments, and transparent to upper protocol layer.
Features:
1. With selfresearched ASIC as the core, low power consumption and high reliability
2. Industrial lever and modular design, surface mount technology
3. Compliance with telecommunications operating standard, MTBF more than 100,000 hours
4. Using dial switch setting parameter, have loop control function and testing pseudo-random code online
5. Abundant alarm and status indications, equipment working condition is clear, it’s easy to maintenance
6. Setting cache size according by different delayed request of data transmission and picture
transmission
7. DC48V or AC220V power supply
8. Strict on raw material choose and QC to ensure high quality and reliability products
Technical Parameters:
E1 Interface
Connector: BNC (Q9)
Impedance: 75Ω unbalanced/ 120Ω balanced
Line Code: HDB3
Bit rate and tolerance: 2.048Mbit/s±50ppm
Standard: ITU-T G.823
Ethernet Interface
Connector: RJ45
Connector Rate: 10/100M,full/half duplex auto-negotiation, auto-mdi/mdix
Max frame Size: 1552Byte
V.35 Interface
Connector Type: DB25 (match DB25-M34)
Connector Rate: N*64Kbit/s
Clock Type: Local clock, Circuit recover clock, Terminal clock
Data Interface
Connector Type: Standard industry connection terminal
Date Type: RS485/RS422/RS232/switching value
Support Rate: 0-500Kbit/s
Error Rate: <10E-9
Other Parameters
Input Voltage: AC100V~260V/50~60Hz,DC-36~72V
Whole Power: <5W
Working Temperature: -40°C~+70°C
Relative Humidity: <95% (non-condensing)
