Technical specifications and parameters
| Size | Weight Designation | Plain-End Weight
Wpe | Outside Diameter
D | Wall thickness
t | Grade | Upset Ends,for weld-on tool joints | | | | lb/ft | kg/m | in | mm | in | mm | | 2 3/8 | 6.65 | 6.27 | 9.33 | 2.375 | 60.3 | 0.28 | 7.11 | E, X, G, S | Ext.Upset | | 2 7/8 | 10.4 | 9.72 | 14.47 | 2.875 | 73 | 0.362 | 9.19 | E, X, G, S | Int.Upset or Ext.Upset | | 3 1/2 | 9.5 | 8.81 | 13.12 | 3.5 | 88.9 | 0.254 | 6.45 | E | Int.Upset or Ext.Upset | | 3 1/2 | 13.3 | 12.32 | 18.34 | 3.5 | 88.9 | 0.368 | 9.35 | E, X, G, S | Int.Upset or Ext.Upset | | 3 1/2 | 15.5 | 14.64 | 21.79 | 3.5 | 88.9 | 0.449 | 11.4 | E | Int.Upset or Ext.Upset | | 3 1/2 | 15.5 | 14.64 | 21.79 | 3.5 | 88.9 | 0.449 | 11.4 | X, G, S | Ext.Upset or Int.-Ext.Upset | | 4 | 14 | 12.95 | 19.27 | 4 | 101.6 | 0.33 | 8.38 | E, X, G, S | Int.Upset or Ext.Upset | | 4 1/2 | 13.75 | 12.25 | 18.23 | 4.5 | 114.3 | 0.271 | 6.88 | E | Int.Upset or Ext.Upset | | 4 1/2 | 16.6 | 15 | 22.32 | 4.5 | 114.3 | 0.337 | 8.56 | E, X, G, S | Ext.Upset or Int.-Ext.Upset | | 4 1/2 | 20 | 18.71 | 27.84 | 4.5 | 114.3 | 0.43 | 10.92 | E, X, G, S | Ext.Upset or Int.-Ext.Upset | | 5 | 16.25 | 14.88 | 22.16 | 5 | 127 | 0.296 | 7.52 | X, G, S | Int.Upset | | 5 | 19.5 | 17.95 | 26.7 | 5 | 127 | 0.362 | 9.19 | E | Int.-Ext.Upset | | 5 | 19.5 | 17.95 | 26.7 | 5 | 127 | 0.362 | 9.19 | X, G, S | Ext.Upset or Int.-Ext.Upset | | 5 | 25.6 | 24.05 | 35.8 | 5 | 127 | 0.5 | 12.7 | E | Int.-Ext.Upset | | 5 | 25.6 | 24.05 | 35.8 | 5 | 127 | 0.5 | 12.7 | X, G, S | Ext.Upset or Int.-Ext.Upset | | 5 1/2 | 21.9 | 19.83 | 29.52 | 5.5 | 139.7 | 0.361 | 9.17 | E, X, G, S | Int.-Ext.Upset | | 5 1/2 | 24.7 | 22.56 | 33.57 | 5.5 | 139.7 | 0.415 | 10.54 | E, X, G, S | Int.-Ext.Upset | | 6 5/8 | 25.2 | 22.21 | 33.04 | 6.625 | 168.3 | 0.33 | 8.38 | E, X, G, S | Int.-Ext.Upset | | 6 5/8 | 27.72 | 24.24 | 36.06 | 6.625 | 168.3 | 0.362 | 9.19 | E, X, G, S | Int.-Ext.Upset |
All technical specifications and parameters only provides for reference. |
