Model:LHBX-1
Send Inquiry
Portable CNC cutting machine
| Tech Data | |
| Cross Beam Length | 1m.4m |
| Longitudinal Rail Length | 2m-3m |
| Effective Cutting Width (X axis) | 1.2m |
| Effective Cutting Length (Y axis) | 1.5m-2.5m |
| Cutting Mode | Flame only; Plasma only |
| Drive Mode | Single-side |
| Drive Method | Rack and pinion drive for X and Y axes |
| Flame Cutting Thickness | 6-200mm |
| Plasma Cutting Thickness | 1-60mm (according to the specification of plasma power source) |
| Cutting Speed | 0-3500mm per minute |
| Moving Precision | 0.01mm per step |
| Power Source | 220V 50Hz 500-1000W |
| Cutting Gas | Acetylene, Propane |
| Plasma Gas | Pressed air, Oxygen, N2 |
| Torch Height Controller | Electromotion bottom |
