Price:Negotiable
Model:ZN04

Send Inquiry

Redstar mining screen
Material: high carbon steel wire grade 45-70, and 65Mn, etc.
High quality requirement
SGS inspection, CE certificateRedstar mining screenMaterials: high carbon steel wire grade 45-70 and 65Mn, etc.

No.	Grade	Chemical Composition			Wire diameter
		C	Si	Mn	mm
1	45	0.42-0.50	0.17-0.37	0.50-0.80	2.0-6.0
2	50	0.47-0.55	0.17-0.37	0.50-0.80
3	55	0.52-0.60	0.17-0.37	0.50-0.80
4	60	0.57-0.65	0.17-0.37	0.50-0.80
5	65	0.62-0.70	0.17-0.37	0.50-0.80
6	70	0.67-0.75	0.17-0.37	0.50-0.80
7	65Mn	0.62-0.70	0.17-0.37	0.90-1.20	2.0-14.0

 Weave Type:double crimp mining screen, single intermediate crimp mining screen, double intermediate crimp mining screen, lock crimp mining screen, flat top mining screen, pressure welded mining screenQuality requirement:1. Not brittle2. smooth surface suitable tightness3. Precision sueface mesh, aperture founderThe finished wire is inspected by third party, SGS inspection
