Model:60*80 F2.0-8.0
Send Inquiry
Gabions are double twisted hexagonal woven wire mesh compartmented baskets of various sizes and dimensions. Gabions baskets are filled with natural stone to create flexible monolithic gravity mass structures.
We design and supply hexagonal gabion boxes made of heavy hexagonal wire nettings.
Hexagonal gabions sizes: 2m x 1m x 1m, 3m x 1m x 1m, 4m x 1m x 1m, 2m x 1m x 0.5m, 4m x 1m x 0.5m. Custom orders available.
Gabion box or called gabion basket finish can be hot-dipped galvanized, galvanized aluminum alloy or PVC coated, etc.
Gabion boxes applications:
Control and guide of water or flood
Flood bank or guiding bank
Preventing of rock breaking
Water and soil protection
Bridge protection
Strengthening structure of soil
| Hexagonal Wire Netting Gabions | |||
| Opening (mm) | Wire Diameter(metal Wire) (mm) | Wire Diameter (PVC Coate)/ Inner/Outside(mm) | Strands |
| 60x80 | f2.0-2.8 | f2.0/3.0-2.5/3.5 | 3 |
| 80x100 | f2.0-3.2 | f2.0/3.0-2.8/3.8 | 3 |
| 80x120 | f2.0-3.2 | f2.0/3.0-2.8/3.8 | 3 |
| 100x120 | f2.0-3.4 | f2.0/3.0-2.8/3.8 | 3 |
| 100x150 | f2.0-3.4 | f2.0/3.0-2.8/3.8 | 3 |
| 120x150 | f2.0-4.0 | f2.0/3.0-3.0/4.0 | 3 |
