Model:-
This production line has contains decoiler, expanded metal mesh machine, flatten machine, mesh shearing machine.
The mesh size and shape can be changed via change the mould. The machine can expand the low carbon steel plate, aluminum plate, titanium plate, copper plate, etc.
Expanded metal mesh application: building mesh, windows, fence, electrical.
Main technical parameters of Sudan Expanded mesh production line(1) 8T Decoiler
(2) Leveling machine
(3) Sudan Expanded mesh machine
(4) Flatten machine
Principle of expanded mesh flatten machine
The main power of the flatten machine is from the 15kw triple-phase asynchronous motor, the reducer and gear pass the power to the up and lower roller, the distance between the rollers can be adjusted according to the material thickness.
Main parameter:
Model: ABYP-1300
Width: Max. 1300MM
Range of the material thickness:
Stainless steel: 1mm Max. 2mm
Low carbon material: 1-4mm
Roller Diameter: 400-500mm, 2pcs
Working speed: 10-20m/Minute
Motor: 15KW, Power: 380v, 50HZ
Weight (kg): 3050kg
Size (m): 1.94*1.6*2.0M
Controller on the machine, regular speed control
Down Roller max. control by switch protection
