Description : 1) Highly Integrated Sensors and Amplifier

2) Full Stainless Steel Structure

3) Circuit At Zero Position And Gain Without Adjustment

4) Compact, Waterproof And Dust Proof Structure

5) Lower Price

Specification :
INPUT
Pressure Range: 1, 2, 3, 7, 20 350, 700 BAR
15, 30, 50, 100, 300 5000, 10000 PSI

Overload Capability: 2 Times

Measuring Media: No Corrosion On Stainless Steel Gas, Liquid

Operational Mode: Gage

Rated Voltage: 24VDC-36V

OUTPUT
Output Signal: 4-20mA or 1-5V

Comprehensive Precision: 0.5%F. S

Non-Linearity: 0.5%F. STyp.

Repeatability: 0.5%F. STyp.

Output Mode: Two-Wire or Three Wire

ENVIRONMENTAL
Operating Temperature Range: -40-85 degree

Compensation Temperature Range: 25-80 degree

Temperature Drifting: 0.5%F. S/degree

Long-Term Stability: <=0.5%F. S/year

PHYSICAL
Thread Connection: M12*1, 74 degree Cone M20*1.5, 1/4NPT , G1/4, Other Form

Electrical Connection: Cable Connection, Hirschmann

3 1/2LED, LCD Show(Optional)
