Panels

• The welded mesh panels have a length of 2000 mm,2200mm,2500mm and are available in a range of heights from 630 till 2430 mm.
• The panels have vertical barbs of 30 mm that can be placed at the top or at the bottom.
• Mesh sizes are 100 x 50 mm ,200x50mm, 75x100mm
• Wire diameter: Horizontal 3,4,5 mm, Vertical 4,0 mm

 Coating

• hot dipped galvanized
•  PVC-coating,
• hot dipped ,then pvc coated.

 Colours

• Green RAL 6005 standard. RAL series colour is available on request.

 Posts:

     1. peach -shaped post: 100x70mm

     2. square post: 60x60mm, 60x40mm

     3. round post: 48mm, 60mm.
