Model:QKGWNO8
Delivery date:Since payment date 20 Days delivery
Packaging & Delivery
| Packaging Detail: | waterproof paper,be packed in seaworthy |
| Delivery Detail: | 20days after deposit or L/C |
Galvanized welded wire mesh
Wire Guage:bwg8~bwg26
Aperture:1/4",3/4",1/2",1",1-1/2",2",3",4"
Width:0.914~2m Length:15m~50m
Welded wire mesh
Our factory can design and manufacture welded wire mesh made of low carbon wire, high carbon wire,stainless steel wire,brass wire.
The finish of welded wire mesh that we produced includes hot-dipped galvanized,electro galvanized,stainless steel,pvc coated.
Characteristics:
Our welded wire mesh enjoys many perfect characteristics therefore this kind of product is one of the most popular products that we produced.
Welded wire mesh has the characteristics of corrosion resistance, acid resistance, alkali resistance and weather proof under natural destroy.
Our welded wire mesh has strong anti-pressure ability and strength. It will not collapse even under big scope of deforming. Welded wire mesh is more economic than other similar products.
Our welded wire mesh enjoys the advantage of good permeation. Then it can prevent the damage by hydrostatic.
The transport freight of welded wire mesh is very low. It can be folded together for transport and further installation.
Applications:
Welded wire mesh is widely used in many fields, including agriculture, industry and construction fields.
Specifications of Welded Wire Mesh:
| Specification List of Welded Wire Mesh | ||
| Opening | Wire Diameter(BWG) | |
| In inch | In metric unit(mm) | |
| 1/4" x 1/4" | 6.4mm x 6.4mm | 22,23,24 |
| 3/8" x 3/8" | 10.6mm x 10.6mm | 19,20,21,22 |
| 1/2" x 1/2" | 12.7mm x 12.7mm | 16,17,18,19,20,21,22,23 |
| 5/8" x 5/8" | 16mm x 16mm | 18,19,20,21, |
| 3/4" x 3/4" | 19.1mm x 19.1mm | 16,17,18,19,20,21 |
| 1" x 1/2" | 25.4mm x 12.7mm | 16,17,18,19,20,21 |
| 1-1/2" x 1-1/2" | 38mm x 38mm | 14,15,16,17,18,19 |
| 1" x 2" | 25.4mm x 50.8mm | 14,15,16 |
| 2" x 2" | 50.8mm x 50.8mm | 12,13,14,15,16 |
