Model:1/4"-6"
WELDED WIRE MESH
MATERIALMedium or low carbon steel wire, stainless steel wire
WELDED WIRE MESH IS MADE OF HIGH QUALITY STEEL WIRE THROUGH AUTOMATIC PROCESS AND SOPHISTICATED WELDING TECHNIQUE, LAID HORIZonTALLY AND VERTICALLY, INDIVIDUALLY WELDED AT EVERY INTERSECTION. THE END PRODUCTS IS LEVEL AND FLAT WITH STURDY STRUCTURE.
WELDED WIRE MESH IS EXTENSIVELY USED IN INDUSTRY AND AGRICULTURE, BUILDING, TRANSPORTATION AND MINING FOR ALL SUCH PURPOSES AS POULTRY HOUSES, EGG BASKETS, RUNWAY ENCLOSURES, DRAINING RACK, FRUIT DRYING SCREEN, FENCE.
STANDARD MESH IN ROLL OF 5M,10M,25M,30M AND 45M LONG AND 0.5M-1.8M WIDE | ||
MESH | WIRE GAUGE | |
INCH | MM | (BWG) |
1/4*1/4 | 6.4MM*6.4MM | 22,23,24,25 |
3/8*3/8 | 10.6MM*10.6MM | 19,20,21,22 |
1/2*1/2 | 12.7MM*12.7MM | 16,17,18,19,20,21,22,23,24 |
5/8*5/8 | 16MM*16MM | 18,19,20,21 |
3/4*3/4 | 19.1MM*19.1MM | 16,17,18,19,20,21 |
1*1 | 25.4MM*25.4MM | 14,15,16,17,18,19,20 |
1-1/2* 1-1/2 | 38MM*38MM | 14,15,16,17,18,19 |
1*1/2 | 25.4MM*12.7MM | 16,17,18,19,20,21 |
1*2 | 25.4MM*50.8MM | 14,15,16,17,18,19 |
2*2 | 50.8MM*50.8MM | 12,14,15,16,17,18 |
3*3 | 75MM*75MM | 16,17,18 |
4*4 | 100MM*100MM | 12,14,15,16 |
6*6 | 150MM*150MM | 12,14,16 |
Assortments Available::
HOT-DIPPED GALVANISED AFTER WELDING
HOT-DIPPED GALVANISED BEFORE WELDING
ELETRIC-GALVANISED AFTRE WELDING
ELETRIC-GALVANISED BEFORE WELDING
PVC-COATED
IN STAINLESS STEEL
PACKING:1) EACH ROLL PACKED IN WATERPROOF PAPER
2) EACH ROLL SHRINK WRAPPED
*Other packing and sizes available at customers request
