ER5356

SPECIFICATIONS CLASSIFICATIONS

AWS A5.10 AWS ER5356

ASME SFA 5.10

DEscriptION / APPLICATION

Galaxy Alloy 5356 is 5% magnesium aluminum filler

metal. The weld deposit of this filler metal offers good

Corrosion resistance when exposed to salt water. This

Alloy is commonly used on base metals 5050,5052,

5083,5356,5454 and 5456.



Chemical composition (%);

Si       <0.25

Fe       <0.40

Cu      <0.10

Mn      0.05~0.20

Mg      4.50~5.50

Zn      <0.10

Ti       0.06~0.20

Cr       0.05~0.2

Spec:

MIG-0.8MM, 0.9MM, 1.0MM, 1.2MM, 1.6M

TIG-1.6MM, 2.0MM, 2.4MM, 3.2MM, 4.0MM

Packaging:

MIG-6kg/ Spool (D300),2kg/Spool (D200),0.5kg/Spool (D100)

TIG-5kg/Carton,10kg/Carton
