Welded Wire Mesh
Welded wire mesh is made of high quality Steel wire through automatic process and sophisticated welding technique. Laid horizontally and vertically. The finished products is Strong Welding, Insistance and Flat with sturdy structure.
Welded wire mesh is used in Industry and Agriculture Building, Transportation and Mining for all such purposes as Poultry Houses, Egg Baskets, Runway Enclosures, Draining Rack, Fruit Drying screen, Fences, etc.
Assortments available:
Material: Low carbon steel wire, stainless steel wire
Hot Dipped Galvanized AFTER/BEFORE Welding;
Electro Galvanized AFTER/BEFORE Welding;
PVC Coating With Green, Black, Color, etc.
shape : roll and sheet |
|
Specification List of Welded Wire Mesh | Opening | Wire Diameter<BWG> | In inch | In metric unit(mm) | 1/4" x 1/4" | 6.4mm x 6.4mm | 22,23,24 | 3/8" x 3/8" | 10.6mm x 10.6mm | 19,20,21,22 | 1/2" x 1/2" | 12.7mm x 12.7mm | 16,17,18,19,20,21,22,23 | 5/8" x 5/8" | 16mm x 16mm | 18,19,20,21, | 3/4" x 3/4" | 19.1mm x 19.1mm | 16,17,18,19,20,21 | 1" x 1/2" | 25.4mm x 12.7mm | 16,17,18,19,20,21 | 1-1/2" x 1-1/2" | 38mm x 38mm | 14,15,16,17,18,19 | 1" x 2" | 25.4mm x 50.8mm | 14,15,16 | 2" x 2" | 50.8mm x 50.8mm | 12,13,14,15,16 | Technical Note:
1,Standard roll length: 30m;width: 0.5m to 1.8m
2,Special sizes available at request
3,Packing: in waterproof paper in rolls. Custom packing available at request. |
|
| |
| Specification of Welded Wire Mesh Panels |
| |
Specification of Welded Wire Mesh Panels | Mesh Size | Wire Diameter | Panel Width & length | In MM | In Inch | MM | 12.7mm | 1/2Inch | 1.0mm - 2.0mm | 3Feet x 6Feet
4Feet x 8Feet
5Feet x 10Feet
1M X 2M 1.5M X 3M
2M X 4M
Other panel sizes can also be made according to request | 25.4mm | 1Inch | 1.5mm - 3.5mm | 31.8mm | 1 1/4Inch | 2.0mm - 4.0mm | 38.1mm | 1 1/2Inch | 2.0mm - 5.0mm | 50.8mm | 2Inch | 2.0mm - 6.0mm | 76.2mm | 3Inch | 3.0mm - 7.0mm | 101.6mm | 4Inch | 3.0mm - 8.0mm | 127mm | 5Inch | 4.0mm - 9.0mm | 152.4mm | 6Inch | 4.0mm - 10.0mm |
|
| |
Galvanized Fencing Mesh | Opening | Wire Diameter<BWG> | In inch | In metric unit(mm) | 2" x 3" | 50mm x 75mm | 2.0mm,2.5mm,1.65mm | 3" x 3" | 75mm x 756mm | 2.67mm,2.41mm,2.11mm,1.83mm,1.65mm | 2" x 4" | 50mm x 100mm | 2.11mm,2.5mm | 4" x 4" | 100mm x 100mm | 2.0mm,2.5mm | Technical Note:
1,Standard roll length: 30m;width: 0.5m to 1.8m
2,Special sizes available at request
3,Packing: in waterproof paper in rolls. Custom packing available at request. |
|
| |
PVC Coated Welded Mesh | Opening | Wire Diameter<BWG> | In inch | In metric unit(mm) | 1/2" x 1/2" | 12.7mm x 12.7mm | 16,17,18,19,20,21 | 3/4" x 3/4" | 19mm x 19mm | 16,17,18,19,20,21 | 1" x 1" | 25.4mm x 25.4mm | 15,16,17,18,19,20 | Technical Note:
1,Standard roll length: 30m;width: 0.5m to 1.2m
2,Special sizes available at request
3,Packing: in waterproof paper in rolls. Custom packing available at request |
|
