Material: low carton steel wire, Al-Mg ally wire .

Process:weaving and welding.Fence length 2m, 2.5m as standard .

Uses:Prevention for road, railway,airport, resistancce district, seaport, garden, feeding and husbandry.

1.Product info:

Panels:

The welded mesh panels have the length of 2000mm, 2200mm,2500mm and available in a range of height from 630 till 2430mm.The panels have vertical bars of 30mm that can be placed at the top or at the bottom.

Mesh size: 100x50mm, 200x50mm, 75X150mm

Wire diameter: Horizontal 3,4,5mm, Vertical 4mm

Coating: hot dipped galvanized, pvc-coated, hot dipped then pvc coated.

Colours: Green RAL 6005 standard. RAL series color is available on request.

Posts:

1)peach-shape post: 100x70mm

2)square post: 60x60mm, 60x40mm

3)round post: 48mm, 60mm

2.Fittings

1)steel clips or plastic clips

2)plastic anti-rain caps

3)base plate if need
