frp horizontal tank machine - Sell

frp horizontal tank machine

2016-10-26 08:39 Views:86

Price:Negotiable
Model:FWJS-3000

1.FRP/GRP tank Continuous winding machine
2.simple control
3.stable quality
4.on-site operation

FRP Horizontal Tank and Septic Tanks Winding Machine

1.Performance Feature

Horizontal winding machine of FRP vessel is mainly used to produce and manufacture the FRP horizontal winding molded vessels as well as the related winding molded products, such as FRP storage tank, fermentation tank, integral septic tank,large FRP chimney, FRP transportation tank, FRP tank for water treatment and etc.

It is divided into DN4000MM and DN4000-DN10000mm winding machine. The winding machine below DN4000mm is used in the workshop for producing vertical and horizontal tanks. While the DN4000-DN10000mm winding machine is fit for manufacturing on site. It can save the manufacturing cost and transportation problem effectively.

2.Main specification and technical parameters are as follows:

Optional Collocation: Cantilever beam tank mould

Pneumatic glass fiber chopped spray gun

Resin Agitating Tank

FRP/GRP horizontal Tank Winding Machine

Get Latest Price

To get an accurate quote from the supplier, enter your detailed requirements below:

From: jenny@hebcygroup.com area id="gp-deftextarea" value="Example: Add order quantity, product type etc.">Example: Add order quantity, product type etc.area> area id="gp-textarea" style="display: none" name="content">Dear Ms. Jenny Liu,Please send me your best price for FRP/GRP horizontal Tank Winding Machinearea> Enter between 20 to 8,000 characters.OK

Email to this supplierFrom: To:Ms. Jenny Liu Subject: Message: area id="fsFB1341471029793_content" class="fb_ele_content fb_ele_hint">area> Enter your inquiry details such as:

Self introduction
Required specifications
Inquire about price/MOQ

View sample Send

.j-ta-wrap { background: none repeat scroll 0 0 #FFFFFF; border-color: none; border-right: 0; border-style: none; border-width: 0; margin-top: -5px; padding: 1px; width: 98%; } .j-ta-wrap .j-ta-inner h3 { font: bolder 16px arial; margin: 0; padding: 0 0 5px; height:auto; background:none; color:#000000;}

« Prev Product 1 2 3 4 5 6 Next Product »

Other Products from this Supplier

FRP/GRP horizontal Tank Winding Machine FRP/GRP Continuous winding machine FRP/GRP Vertical Tank Winding Machine RPMP Production Line Double duty machine of core and mould Electric pipe winding machine FRP winding machine Curing machine for FRP/GRP Winding Machine RPMP Production Line FRP tank

See more FRP Horizontal Tank Winding Machine , frp filament winding machine , fiberglass winding machine products from this supplier.

.helplink p.post_rfq_link {background:transparent url('http://img.alibaba.com/simg/single/icon/icon_rfq_20.gif') no-repeat scroll left top;padding-left:28px;} .tmd-che-dan{margin:10px 0 0 -28px;vertical-align:-3px} Want to get more exact suppliers with detailed quotations? Post an RFQ now>>
Not sure about product quality? Find reliable inspectors to help ensure product quality!

Shijiazhuang Chenying Imp&Exp Co., Ltd. [ Hebei, China (Mainland) ] onsite Checked Add Company to Favorites
Product Showcase[15]
Products [47]
FRP products [3]
FRP tank [7]
Moulds for FRP pipe/tank [1]
Parts for FRP/GRP machine [13]
FRP/GRP tank production line [6]
FRP/GRP pipe production line [12]
FRP production line(whole) [5]

Company Profile
Quality Control
R&D
Management
Contact Person
Ms. Jenny LiuI'm Online
Chat Now!View Contact Details
Model
Parameters
FWWS-4000
FWWS-10000
Tank winding machine
Septic tank
Production diameter (mm)
φ300mm-φ1000mm
φ1000mm-φ4000mm
φ4000mm- φ10000mm
Production length (mm)
≤1200
≤1200
range of Winding angle
45°—90°
45°—90°
RPM of Principal Mandrels (r/ min)
≤34
≤12
Max speed of pulling yarn (m/min)
≤120m/min
≤120m/min
Max width of yarn (mm)
220
220
Production capacity (kg/h)
1200
2000
Total installed capacity (KW)
12
18.5
Areas covered by production line (length×width )m
20×10
22×15

Optional Collocation: Cantilever beam tank mould
Pneumatic glass fiber chopped spray gun
Resin Agitating Tank
