Model:-
This plastic soft hose transpanent and nonpoison,pressureresist,pullresist,corrosio-nresist,beautiful outlook,soft ,light and long-lasting.It can be widely used in sanitary foodstuff industry,It is really the best choice for transporting air,water,gas and under the temperature conditions from 5 degree below zero to 65 degree above zero.
measurement | Metric Measurement | Weight | Length | W.P. | B.P. | Packing Measurement | ||
I.D. | O.D. | Diameter | Height | |||||
inch | mm | mm | kg/roll | m | Bar | Bar | mm | mm |
13/64 | 5 | 9 | 10 | 170 | 9 | 30 | 400 | 140 |
1/4 | 6 | 10 | 10 | 148 | 8 | 27 | 400 | 140 |
6 | 11 | 10 | 112 | 10 | 30 | 400 | 140 | |
6 | 12 | 10 | 88 | 15 | 40 | 400 | 140 | |
5/16 | 8 | 12 | 10 | 118 | 9 | 24 | 420 | 160 |
8 | 13 | 10 | 90 | 10 | 30 | 420 | 160 | |
8 | 14 | 10 | 72 | 12 | 32 | 450 | 160 | |
3/8 | 9 | 13 | 10 | 108 | 7 | 27 | 450 | 160 |
9 | 14 | 10 | 83 | 8 | 30 | 450 | 160 | |
13/32 | 10 | 14 | 10 | 100 | 7 | 24 | 450 | 160 |
10 | 15 | 10 | 76 | 8 | 25 | 450 | 160 | |
10 | 16 | 10 | 61 | 10 | 30 | 450 | 160 | |
1/2 | 12 | 16 | 20 | 169 | 7 | 20 | 560 | 180 |
12 | 17 | 20 | 130 | 9 | 21 | 560 | 180 | |
12 | 18 | 20 | 105 | 10 | 27 | 560 | 180 | |
1/2 | 13 | 17 | 20 | 158 | 5 | 15 | 580 | 180 |
13 | 18 | 20 | 122 | 6 | 18 | 580 | 180 | |
13 | 19 | 20 | 99 | 8 | 24 | 580 | 180 |
