CONSTRUCTION: It is made of internal rubber ,middle rubber ,2,4 or 6 layers of wire-wood,and external rubber .The internal rubber bears the pressure of delivery medium in order to protect the steel wire from corrupting while the enforced wire-wood layer increases the firmness of the hose !



APPLICATIONS:It is mainly used for Mine hydraulic support ,oilfield exploitation ,object construction ,lifting transport ,metallurgic forging ,mine equipment, ship, injection molding machinery,agricultural machinery , all kinds of machine tools and various industrial sectors machanization and automation in the hydraulic system of conveying with a certain pressure(high pressure) and the temperature of the oil-based(such as mineral oil, soluble oil, hydraulic oil, fuel oil and lubricants) and water-based liquid (such as Emulsion, the oil-water emulsion, water) and liquid transmission used.The maximum working pressure-resistant up to 70-100MPa.



REMARK: Ther standard pls reference to GB/T10544-03,DIN20023,SAE100R9~13. The standards are not suitable for castor oil-and urethano liquid.



ADVANTAGE:

1.Selection of synthetic rubber hose with special made, with excellent  oil resistance, heat resistance, anti-aging properties.

2,Hose for the high-pressure and superior pulse properties.

3,Hose combination of close,use soft,small defomation under pressure.

4, Hose has an excellent circumnutate resistance and fatigue resistance.

5, Hose length of 20 metres ,and made on request within 50 metres.

WORKING TEMPERATURRE : -30+120
