Hot-dip Galvanized steel pipe
1)Thickness:2.77-6.02mm
2)OD:21.3-114.3mm
3)Application:Structure
4)Certification:ISO9001:2000

1)Product Name:ASTM A53 Hot-dip Galvanized steel pipe

2)Place of Origin:Nantong China(Mainland)

3)OD(mm):21.3  26.7  33.4  42.2  48.3  60.3  73.0  88.9  114.3

4)Nominal thickness(mm):2.77  2.87  3.38  3.56  3.68  3.91  5.16  5.49  6.02

5)Coefficient(c):1.064 1.051 1.045 1.040 1.036 1.034 1.032 1.028

6)Steel grade:Q215A  Q215B  Q235A  Q235B

7)Standard weight class:STD

8)Class A test pressure(Mpa):4.83MPa-13.10Mpa

9)Test pressure value(Mpa): D10.2-168.3mm to 3Mpa, D177.8-323.9mm to 5Mpa

10)Weight(Black Tube)(kg/m):1.27kg/m-16.07kg/m
