Thickness:1 mm to 30 mm

Suit for:Electricity distribution

Shape:Conoid ,Multi-pyramidal , Columniform,polygonal or conical

Material:Usually   Q345B/A572,minimum yieldstrength>=345n/mm2

As well as Hot rolled coilfrom Q460 ,ASTM573 GR65, GR50 ,SS400, SS490, to ST52-

Tolerance of dimension:+- 2%

Power:10  KV ~550 KV

Safety Factor:Safety factorfor conducting wine : 8

             Safety factor for grounding wine :8

Design Load in Kg:300~ 1000Kg applied to 50cm from the top pole

Marks:Nane plate throughrivert or glue ,engrave ,emboss as per customer requirement

Surface treatment:Hot dipgalvanized Following ASTM A 123, color polyester power or any other standard byclient required.

Joint of Poles:Insertmode,innerflange mode,face to face joint mode .

Design of pole:Againstearthquake of 8 grade

Wind Speed:160 Km/Hour .  30 m /s

Minimum yield strength:355mpa

Minimum ultimate tensilestrength:490 mpa

Max ultimate tensile strength:620mpa

Standard:ISO 9001
